Reverse Engineering A Printer Driver For Linux

Context

I have this Ricoh SP 200 printer, a simple and cheap black-and-white laser printer. The issue is that the official drivers are only available for Windows. CUPS on Linux is excellent and supports most printers out of the box, so naturally I tried everything: foo2zjs, OpenPrinting, HPLIP, Gutenprint. Nothing. This printer is truly one of a kind in the worst possible way.

My only option was a Windows VM with USB passthrough, which worked but required booting into a VM just to print something. So I decided to take matters into my own hands and write the driver myself. How hard could it be?

The approach

Since the printer only connects over USB, I had two paths:

• Capture USB traffic while the Windows driver prints, and reverse-engineer the protocol from the wire.
• Disassemble the Windows driver with something like Ghidra.

A signed, packaged Windows driver might be obfuscated, and decompiling a large driver binary is a significant effort. USB traffic, on the other hand, is plaintext on the wire and the printer speaks some protocol, and the driver is just sending bytes. I decided to start with capture.

Capturing the traffic

On Windows, there’s a tool called USBPcap that hooks into the USB stack and captures all transfers to and from a selected device. It’s CLI-based: run it, pick the USB host controller that your printer is on, start capturing, print something, stop capturing. It hands you a .pcap file that Wireshark understands natively.

I booted the Windows VM, attached the printer, installed USBPcap, and printed a single-page PDF. Then I pulled the capture file over to my Linux machine and opened it in Wireshark.

First look: the single-page capture

The raw capture has a lot of noise like USB control transfers, device enumeration, interrupt transfers for status polling. I only care about bulk transfers going to the printer (host -> device direction). In Wireshark’s filter bar:

usb.transfer_type == 0x03 && usb.endpoint_address.direction == 0

transfer_type == 0x03 means bulk , and direction == 0 (OUT) means host-to-printer. Running the same filter with tshark on the command line gives a clean view:

$ tshark -r ricoh.pcap -Y "usb.transfer_type == 0x03 && usb.endpoint_address.direction == 0"

  19  58.923040  host -> 1.3.1  USB 65563 URB_BULK out
  20  59.151066  1.3.1 -> host  USB    27 URB_BULK out
  21  59.151359  host -> 1.3.1  USB 59703 URB_BULK out
  22  59.189228  1.3.1 -> host  USB    27 URB_BULK out

Frames 20 and 22 are the printer’s ACK responses (27-byte URB headers, no data). The real action is in frames 19 and 21: two bulk OUT transfers, 65,536 and 59,676 bytes of actual payload, respectively. One page of printing produces about 125 KB of data over USB.

Decoding the first packet

The first thing to do with an unknown binary format is run strings on it and see what comes out. Extracting the raw payloads from both transfers:

$ tshark -r ricoh.pcap \
    -Y "usb.transfer_type == 0x03 && usb.endpoint_address.direction == 0" \
    -T fields -e usb.capdata \
    | while read hex; do echo "$hex" | xxd -r -p | strings; done

Output (printable strings extracted from binary):

%-12345X@PJL
@PJL SET TIMESTAMP=2026/05/14 12:54:44
@PJL SET FILENAME=Aryan Kushwaha Resume - AryanKushwaha_Resume.pdf
@PJL SET COMPRESS=JBIG
@PJL SET USERNAME=archputer
@PJL SET COVER=OFF
@PJL SET HOLD=OFF
@PJL SET PAGESTATUS=START
@PJL SET COPIES=1
@PJL SET MEDIASOURCE=TRAY1
@PJL SET MEDIATYPE=PLAINRECYCLE
@PJL SET PAPER=A4
@PJL SET PAPERWIDTH=4961
@PJL SET PAPERLENGTH=7016
@PJL SET RESOLUTION=600
@PJL SET IMAGELEN=65556
[binary data ...]
@PJL SET DOTCOUNT=2168280
@PJL SET PAGESTATUS=END
@PJL EOJ
%-12345X

That’s immediately recognizable. %-12345X is the Universal Exit Language (UEL) sequence, as referenced from PJL Quick Reference . It’s the standard “wake up the printer” prefix used by HP-derived print protocols. @PJL is Printer Job Language, a text-based meta-layer that wraps print data and carries job settings. The printer is speaking PJL.

This is a much better starting point than I expected. No proprietary binary format, no obfuscation, just text commands followed by compressed image data.

What the PJL header tells us

Working through the commands one by one:

The COMPRESS=JBIG line was the find that mattered. JBIG (Joint Bi-level Image Experts Group) is an international standard for compressing binary images - ITU-T T.82, finalized in 1993. It’s designed precisely for this: monochrome laser printer output at high resolution. I had initially guessed the printer might use HBPL2 (used by many other Ricoh printers in foo2zjs), but grepping for HBPL in the raw stream finds nothing. This is pure PJL + JBIG1.

The JBIG BIE header

Immediately after the IMAGELEN=65556\r\n text, the binary image data begins. Looking at those bytes in the hex dump:

$ tshark -r ricoh.pcap -Y "frame.number == 19" -x | grep -A1 "65556"

01d0  36 35 35 35 36 0d 0a 00 00 01 00 00 00 13 61 00   65556.........a.
01e0  00 1b 68 00 00 00 80 00 00 03 48 04 c0 32 87 e8   ..h.......H..2..

After the \r\n terminator of the IMAGELEN command, the 20-byte JBIG1 BIE (Bi-level Image Entity) header starts:

00 00 01 00  00 00 13 61  00 00 1b 68  00 00 00 80  00 00 03 48

The JBIG1 BIE header format (ITU-T T.82, §6.2.1):

I initially assumed those 20 bytes were a proprietary Ricoh header on top of the JBIG stream. They’re not, it’s a completely standard BIE header. The 4961 and 7016 values confirmed it: A4 paper at 600 dpi is exactly 210 mm × (600/25.4) = 4961 pixels wide, and 297 mm × (600/25.4) = 7016 pixels tall.

Bytes 18 and 19: the order and options flags, turned out to be important later. I noted their exact values: 0x03 and 0x48.

My initial hypothesis was wrong

My first assumption before even looking at the capture was that this printer used the same protocol as other Ricoh/Gestetner printers supported by foo2zjs - specifically the HBPL2 (Host-Based Printer Language 2) format. HBPL2 is what foo2hbpl2 implements.

After extraction I grepped the entire raw binary stream for HBPL:

$ tshark -r ricoh.pcap -T fields -e usb.capdata | xxd -r -p | grep -a "HBPL"
(no output)

Nothing. And searching the jbigkit source, the JBIG compression algorithm is documented in ITU-T T.82, a public standard with publicly available implementations. The jbigkit library (libjbig) implements it exactly. So I had a basic overview: PJL header -> JBIG1 BIE -> implement with jbigkit -> done. Or so I thought.

A little bit about CUPS

Before writing any code, I needed to understand what I was building into. CUPS (Common Unix Printing System) is the printing subsystem on Linux (and macOS). When you send a document to a printer, CUPS is the thing that takes it from “file on disk” to “bytes going down USB”. It does this through a filter chain, a series of programs that progressively transform the document from its source format into whatever language the printer speaks.

A typical CUPS print job flows like this:

Application
    ↓  (PDF, PostScript, image, text)
CUPS scheduler
    ↓
ghostscript / pdftoraster   ← converts the document to a generic raster image
    ↓
CUPS raster stream          ← format-neutral: one page at a time, raw pixels
    ↓
[printer-specific filter]   ← converts raster to the printer's native format
    ↓
USB / network               ← bytes to the physical device

The piece we need to write is the printer-specific filter: a small program that reads the CUPS raster stream from stdin and writes the printer’s native wire format to stdout. CUPS invokes it automatically whenever a job is sent to the printer.

A CUPS filter is invoked with five arguments:

filter  job-id  user  title  copies  options

It reads raw pixel data from stdin (one row at a time via cupsRasterReadPixels) and writes whatever the printer expects to stdout. It knows the page dimensions, resolution, and color space from the per-page header (cups_page_header2_t) that CUPS prepends to each page’s raster data.

The second piece is the PPD file (PostScript Printer Description). PPD is an old Adobe format that CUPS still uses to describe a printer’s capabilities: which paper sizes it supports, what resolution, and most importantly - which filter program to call and in what pixel format to deliver the raster data. The PPD is what tells CUPS “for this printer, run rastertoricohjbig and give it 1-bit monochrome raster”.

So concretely, we need to produce two files:

Now I had enough context to start writing.

Building the first driver

Armed with the protocol understanding, I started writing a CUPS filter. A CUPS filter reads a raster page stream from stdin (provided by CUPS) and writes the printer’s native format to stdout. The filter chain is:

PDF/PostScript -> ghostscript -> CUPS raster -> [our filter] -> PJL+JBIG1 -> USB

The filter needs:

1. libcups / libcupsimage: to read the CUPS raster stream
2. libjbig (jbigkit): to JBIG-encode each page’s raster bitmap

The basic structure:

cups_raster_t *ras = cupsRasterOpen(0, CUPS_RASTER_READ);
cups_page_header2_t hdr;

write_job_header(copies);

while (cupsRasterReadHeader2(ras, &hdr)) {
    unsigned char *bmp = malloc(hdr.cupsBytesPerLine * hdr.cupsHeight);
    for (unsigned y = 0; y < hdr.cupsHeight; y++)
        cupsRasterReadPixels(ras, bmp + y * hdr.cupsBytesPerLine, hdr.cupsBytesPerLine);
    encode_and_send_page(bmp, hdr.cupsWidth, hdr.cupsHeight);
    free(bmp);
}

fputs("@PJL EOJ\r\n\x1b%-12345X\r\n", stdout);

I registered the printer with CUPS using lpadmin, set up a minimal PPD file, and tried to print.

The printer made no sound whatsoever. No motor spin, no LED activity. The job silently disappeared.

Bug 1: the missing bare @PJL line

I diffed my driver’s hex output against the captured Windows driver output for a while before spotting the difference. My driver emitted:

ESC%-12345X@PJL SET TIMESTAMP=...

The Windows driver emitted:

ESC%-12345X@PJL\r\n
@PJL SET TIMESTAMP=...

Notice the @PJL\r\n on its own line, immediately after the UEL. This is a bare PJL “enter PJL mode” command with no arguments. Without it, the printer’s firmware apparently never transitions into PJL command-parsing mode and drops the entire job silently.

After looking it up, this appears to be a quirk of the Ricoh firmware’s PJL parser: the UEL and the first PJL command must be on separate lines. Most PJL documentation mentions the bare @PJL as optional, but for this firmware it’s required.

Fix:

fputs("\x1b%-12345X@PJL\r\n", stdout);
// Now emit the actual SET commands

After the fix: the printer’s motor spun up, the LED flashed, the page feed mechanism started… and then stopped. The printer initialised but never pulled the paper.

Bug 2: the missing PAPERLENGTH

I went back to the hex dump. My driver’s PJL header included PAPERWIDTH=4961, I had that. But I had omitted PAPERLENGTH=7016, thinking width alone would be enough to define A4.

The Windows capture has both:

@PJL SET PAPERWIDTH=4961
@PJL SET PAPERLENGTH=7016

Without PAPERLENGTH, the printer’s print engine initialises (it has enough to set its page buffer width) but never gets the page length it needs to know when to stop pulling paper. The firmware just sits there waiting for a length it will never receive.

Fix: emit both dimensions every page.

After the fix: the motor ran, the paper fed all the way through, and I got a page out of the printer. It was completely blank.

Bug 3: the wrong JBIG options byte

A blank output page means the printer received and understood the job structure, but the image data itself was malformed or misinterpreted. I had my JBIG encoding wrong somewhere.

The jbigkit API requires setting encoding options before calling jbg_enc_out():

jbg_enc_init(&enc, w, h, 1, planes, callback, &buf);
jbg_enc_options(&enc, order, options, l0, mx, dmax);
jbg_enc_out(&enc);

The fix only makes sense once you understand how JBIG actually encodes pixels — specifically, that the options byte isn’t metadata, it’s a choice of algorithm.

How JBIG encodes pixels

JBIG1 is a lossless compressor for binary (1-bit) images. The core idea is context-based arithmetic coding. To encode a pixel, the encoder looks at a set of already-encoded neighboring pixels, called the prediction context or template, and uses their values to estimate the probability that the current pixel is black or white. A pixel that’s likely white (e.g., surrounded by white neighbors in a mostly-blank area) gets a short code; a pixel that’s unlikely (e.g., a black pixel in a white field) gets a longer code. Arithmetic coding exploits these probabilities to produce a compact bitstream.

The critical part: the encoder and decoder must agree on exactly which neighboring pixels to use as context. The template defines the shape of the context window, that is which pixel positions, relative to the current pixel, contribute to the prediction. If the encoder builds contexts using one set of pixel offsets and the decoder decodes using a different set, they are operating on fundamentally different data, and the output will be garbage.

The options byte bitfield

BIE byte 19 is the options field. In jbigkit 2.1 (from jbig.h):

#define JBG_LRLTWO  0x40  /* use two-line template for lowest-resolution layer */
#define JBG_TPDON   0x08  /* typical prediction for differential layers */
#define JBG_TPBON   0x04  /* typical prediction for bottom-up coding */
#define JBG_DPON    0x02  /* deterministic prediction */
#define JBG_DPPRIV  0x01  /* use private deterministic prediction table */

0x48 is JBG_LRLTWO | JBG_TPDON. My initial guess of 0x08 was JBG_TPDON alone — missing JBG_LRLTWO.

What LRLTWO actually does

The lowest-resolution layer uses a 10-pixel context window. The LRLTWO flag selects between two different shapes for that window:

Three-line template (LRLTWO not set, 0x08):

  . X X X X     ← two rows above current pixel
  X X X X .     ← one row above
  X X [?]       ← current row (? = pixel being encoded)

Two-line template (LRLTWO set, 0x48):

  X X X X X X   ← one row above current pixel
  X X X X [?]   ← current row

Both use 10 context pixels, but from different spatial positions. The encoder uses these 10 bits as an index into a probability table: 2^10 = 1024 entries. That it updates adaptively as it scans the image. The decoder has its own copy of the same 1024-entry table and must build the same 10-bit index from the same pixel positions to look up the same probabilities.

Why mismatching templates produces all-black

A blank page. The jbigkit 2.1 source then revealed something important: jbg_enc_options() stores the options argument directly into BIE byte 19, with no bit translation. So whatever I pass is what appears verbatim in the header. I was encoding with 0x08 and declaring 0x08. But the Windows capture showed 0x48.

My first attempt at fixing this was wrong in a subtle way: I patched BIE byte 19 manually to 0x48 after jbigkit had already encoded the stream. I thought the byte was a capability flag which just tells the printer which mode to expect, so changing the declared value without re-encoding seemed harmless.

The result was a completely black page.

Adding debug logging to count the black pixels before encoding confirmed the bitmap itself was correct:

Filter invoked!
--- page 1 ---
  Width=4961  Height=7016  DPI=600
  ColorSpace=3  BitsPerColor=1  BitsPerPixel=1
  page 1 encoded and sent

Done. Total pages=1  total_dots=9585

total_dots=9585 — correct for a page with a few lines of text. The input was fine. The problem was the JBIG stream the printer was decoding.

What had happened: the stream was encoded using the three-line context template (0x08), but the header I patched now declared the two-line template (0x48). The printer’s decoder initialised its 1024-entry probability table for the two-line template shape and started reading context pixels from the two-line positions. The contexts it computed had nothing to do with the contexts the encoder used to produce those bits. The arithmetic coder started with a flat 50/50 probability distribution; without the correct contexts, every decoded pixel drifted toward the wrong value. The errors also cascade, each wrongly decoded pixel becomes part of the context for the next pixel. So, a single initial mismatch compounds across the entire image. The decoder effectively assigned maximum surprise to almost every pixel, producing solid black.

The fix: pass 0x48 to jbg_enc_options so that both the encoding and the declared header use the two-line template consistently:

jbg_enc_options(&enc, 0x03, 0x48, 128, 0, 0);

Now the encoder selects the two-line context shape, produces a bitstream built from two-line contexts, and the header correctly declares 0x48. The decoder initialises for the two-line template, reads contexts from the same pixel positions the encoder used, and reconstructs the image correctly.

After the fix: the page came out with actual content, no longer all-black. But the image was garbled. Wrong pixels, wrong proportions. The stream structure was valid; the pixel data feeding into it was not.

Bug 4: CUPS delivering 8-bit grayscale instead of 1-bit packed

My PPD file at this point was minimal, just enough to register the printer. It didn’t tell CUPS what pixel format to deliver to my filter. CUPS defaulted to 8-bit grayscale (one byte per pixel).

My filter read hdr.cupsBitsPerPixel but then calculated the row stride as (width + 7) / 8, assuming 1-bit packed data. With 8-bit grayscale, the actual row is width bytes wide i.e. eight times what I expected. I was reading every 8th pixel’s byte and passing a far-too-narrow bitmap to jbigkit. The JBIG stream was internally valid but encoded the wrong slice of the image.

For a laser printer filter, the correct format is CUPS_CSPACE_K (black channel), 1 bit per pixel, packed 8 pixels per byte. The PPD must declare this explicitly:

*cupsBitsPerColor: 1
*cupsColorSpace: 3
*cupsCompression: 0

ColorSpace 3 is CUPS_CSPACE_K: the black channel, where 1 means black and 0 means white (the opposite of typical grayscale). The filter also needed to use hdr.cupsBytesPerLine from the raster header (the actual stride as CUPS computed it) rather than manually calculating (bpp * w + 7) / 8, which can diverge due to row padding.

After adding the PPD directives and fixing the stride:

First successful page print. A clean, readable printout from Linux, no VM required.

I sent a test page with echo "Hello from Linux" | lpr -P Ricoh_SP_200_DDST and watched a printed page come out. A single page. Now let me try a multi-page document.

The multi-page problem

I printed a two-page PDF. The first page came out fine. The second page never arrived. The printer sat idle, then eventually printed nothing and went back to ready. Job complete according to CUPS, but only one page on the tray.

No error messages. No LED codes. The printer just… dropped page 2 silently.

My first assumption: maybe the JBIG stream for page 2 was malformed. I added debug logging and verified the JBIG encoding was running correctly for both pages. jbigkit encoded two valid BIE streams. Both had correct dimensions and the right options bytes. The data looked fine.

My second assumption: maybe the loop wasn’t iterating for page 2. I added a fprintf(stderr, "PAGE: %d\n", page) and saw both pages being processed. The filter was reading and encoding both pages correctly. But only one was printing.

The problem had to be in the protocol; something in the PJL framing between pages. I needed another capture.

Second capture: a multi-page job

I went back to the Windows VM and printed a two-page document, this time capturing with USBPcap from the start. Importing the capture and running the same tshark filter:

$ tshark -r ricoh_capture.pcap \
    -Y "usb.transfer_type == 0x03 && usb.endpoint_address.direction == 0"

  19  10.184667  host -> 1.3.1  USB 65563 URB_BULK out
  20  10.429456  1.3.1 -> host  USB    27 URB_BULK out
  21  10.430073  host -> 1.3.1  USB 65563 URB_BULK out
  22  10.481597  1.3.1 -> host  USB    27 URB_BULK out
  23  10.482111  host -> 1.3.1  USB 24937 URB_BULK out
  24  10.504719  1.3.1 -> host  USB    27 URB_BULK out

Three bulk OUT transfers (frames 19, 21, 23), each followed by a printer ACK. The single-page job used two transfers totalling ~125 KB. This two-page job uses three transfers: 65,536 + 65,536 + 24,910 = 155,982 bytes.

Extracting the full multi-page protocol

Running the same strings extraction on the three-frame sequence reveals the complete two-page protocol, with binary JBIG data replaced by [... N bytes JBIG ...] for readability:

$ tshark -r ricoh_capture.pcap \
    -Y "usb.transfer_type == 0x03 && usb.endpoint_address.direction == 0" \
    -T fields -e usb.capdata \
    | while read hex; do echo "$hex" | xxd -r -p | strings -n 6; done

Formatted:

%-12345X@PJL
@PJL SET TIMESTAMP=2026/05/15 01:07:17
@PJL SET FILENAME=Guide to Finding Articles_Books.pdf
@PJL SET COMPRESS=JBIG
@PJL SET USERNAME=archputer
@PJL SET COVER=OFF
@PJL SET HOLD=OFF
@PJL SET PAGESTATUS=START
@PJL SET COPIES=1
@PJL SET MEDIASOURCE=TRAY1
@PJL SET MEDIATYPE=PLAINRECYCLE
@PJL SET PAPER=A4
@PJL SET PAPERWIDTH=4961
@PJL SET PAPERLENGTH=7016
@PJL SET RESOLUTION=600
@PJL SET IMAGELEN=65556
[... 65556 bytes JBIG — page 1, chunk 1 ...]
@PJL SET IMAGELEN=13451
[... 13451 bytes JBIG — page 1, chunk 2 ...]
@PJL SET DOTCOUNT=1477935
@PJL SET PAGESTATUS=END
@PJL SET PAGESTATUS=START
@PJL SET COPIES=1
@PJL SET MEDIASOURCE=TRAY1
@PJL SET MEDIATYPE=PLAINRECYCLE
@PJL SET PAPER=A4
@PJL SET PAPERWIDTH=4961
@PJL SET PAPERLENGTH=7016
@PJL SET RESOLUTION=600
@PJL SET IMAGELEN=65556
[... 65556 bytes JBIG — page 2, chunk 1 ...]
@PJL SET IMAGELEN=10550
[... 10550 bytes JBIG — page 2, chunk 2 ...]
@PJL SET DOTCOUNT=1266291
@PJL SET PAGESTATUS=END
@PJL EOJ
%-12345X

This was what I’d been missing. My single-page driver had the page lifecycle completely wrong.

What the multi-page capture taught me

Discovery 1: PAGESTATUS=END is the page eject trigger

The most critical finding: @PJL SET PAGESTATUS=END is what tells the firmware to eject the page. Without it, the printer keeps the current page open, waiting for more IMAGELEN chunks.

My single-page driver had never sent PAGESTATUS=END after the JBIG data. For a single-page job, this didn’t matter: when the job ended (EOJ + UEL), the firmware ejected whatever was buffered. But for multi-page jobs, every subsequent IMAGELEN was treated as another chunk of the still-open page 1. The printer accumulated all pages’ JBIG data as one gigantic page 1, then when the job ended, it ejected it as a single mangled page, or not at all because it became too large for the buffer.

Looking at how the DOTCOUNT and PAGESTATUS sequence work:

[65556 bytes of JBIG — page 1 chunk 1]
@PJL SET IMAGELEN=13451          ← "here comes 13451 more bytes for this same page"
[13451 bytes of JBIG — page 1 chunk 2]
@PJL SET DOTCOUNT=1477935        ← "page 1 had 1,477,935 black pixels"
@PJL SET PAGESTATUS=END          ← "page 1 is done, eject it"

PAGESTATUS=END closes page 1. Only then does the firmware feed the paper through and return ready for page 2.

Discovery 2: multiple IMAGELEN chunks per page

For page 1, the Windows driver sends two separate IMAGELEN blocks: one of 65,556 bytes and one of 13,451 bytes. Total JBIG stream for page 1: 79,007 bytes.

This is chunking. The Windows driver splits any JBIG stream that would exceed the USB bulk transfer limit into consecutive @PJL SET IMAGELEN blocks, each followed by that exact number of bytes of JBIG data. All blocks before the next PAGESTATUS=END belong to the same page.

The 65,536-byte (65,508 usable after USB framing overhead) limit is the USB full-speed bulk transfer maximum that the Windows driver appears to respect. Page 1 needed 79,007 bytes -> chunk 1 is 65,556 bytes -> chunk 2 is the remaining 13,451 bytes.

My Linux filter produces smaller JBIG streams, small enough to fit in a single chunk, but the firmware accepts both chunked and unchunked delivery as long as the framing is correct.

Discovery 3: every page except the first gets its own full header

Looking at what comes between PAGESTATUS=END for page 1 and the first IMAGELEN for page 2:

@PJL SET PAGESTATUS=END          ← closes page 1
@PJL SET PAGESTATUS=START        ← opens page 2
@PJL SET COPIES=1
@PJL SET MEDIASOURCE=TRAY1
@PJL SET MEDIATYPE=PLAINRECYCLE
@PJL SET PAPER=A4
@PJL SET PAPERWIDTH=4961
@PJL SET PAPERLENGTH=7016
@PJL SET RESOLUTION=600
@PJL SET IMAGELEN=65556          ← page 2 data begins

Every page from page 2 onwards needs its own PAGESTATUS=START plus the full media block (COPIES, MEDIASOURCE, MEDIATYPE, PAPER, PAPERWIDTH, PAPERLENGTH, RESOLUTION). Page 1 gets the media block from the job header. Pages 2+ must declare it themselves.

My driver omitted all of this for pages after the first. Without PAGESTATUS=START, the firmware apparently doesn’t initialise its page buffer for the next page, so the incoming JBIG data has nowhere to go.

Discovery 4: DOTCOUNT is required per page

@PJL SET DOTCOUNT=N appears immediately before every PAGESTATUS=END. It reports the total number of black pixels on the page. The printer uses this for toner life estimation. It tracks how many dots it has printed to estimate when toner will run out.

Looking at the values from the capture:

• Page 1 DOTCOUNT: 1477935: a relatively text-heavy page
• Page 2 DOTCOUNT: 1266291: slightly lighter page

My driver was sending no DOTCOUNT at all. From testing, omitting DOTCOUNT in some cases causes the firmware to reject the PAGESTATUS=END that follows it, leaving the page open indefinitely.

Bug 5: cupsBytesPerLine vs manual stride calculation

While fixing the multi-page protocol, I also hit a subtler bug. My filter calculated the row stride as:

unsigned stride = (hdr.cupsBitsPerPixel * hdr.cupsWidth + 7) / 8;

For page 1 this worked fine. But cupsRasterReadHeader2() failed on page 2. It returned 0 and the loop exited after one page.

The cause: CUPS’s internal row stride (cupsBytesPerLine in the header) can include padding bytes that align rows to word boundaries. My manual calculation didn’t account for this padding. When reading the raster stream, if you use the wrong stride, you consume too few or too many bytes per row, misaligning the stream for the next page’s header. cupsRasterReadHeader2 then reads garbage instead of a valid header and returns failure.

Fix: always use hdr.cupsBytesPerLine as the stride, never compute it manually:

unsigned stride = hdr.cupsBytesPerLine;  // not (bpp * w + 7) / 8

CUPS guarantees that cupsBytesPerLine bytes per row are in the stream regardless of actual pixel data width. Trust the header.

The complete protocol structure

With all five bugs found and fixed, the complete PJL+JBIG1 protocol for the Ricoh SP 200 is:

── Job header (once) ──────────────────────────────────────────────────
ESC%-12345X@PJL\r\n
@PJL SET TIMESTAMP=YYYY/MM/DD HH:MM:SS\r\n
@PJL SET FILENAME=...\r\n
@PJL SET COMPRESS=JBIG\r\n
@PJL SET USERNAME=...\r\n
@PJL SET COVER=OFF\r\n
@PJL SET HOLD=OFF\r\n
@PJL SET PAGESTATUS=START\r\n      ← covers page 1
@PJL SET COPIES=N\r\n
@PJL SET MEDIASOURCE=TRAY1\r\n
@PJL SET MEDIATYPE=PLAINRECYCLE\r\n

── Per-page block (repeat for every page) ─────────────────────────────
  [pages 2+ only:]
  @PJL SET PAGESTATUS=START\r\n
  @PJL SET COPIES=N\r\n
  @PJL SET MEDIASOURCE=TRAY1\r\n
  @PJL SET MEDIATYPE=PLAINRECYCLE\r\n

  @PJL SET PAPER=<A4|LETTER>\r\n
  @PJL SET PAPERWIDTH=<px>\r\n
  @PJL SET PAPERLENGTH=<px>\r\n
  @PJL SET RESOLUTION=600\r\n
  @PJL SET IMAGELEN=<N>\r\n
  <N bytes: JBIG1 BIE data>
  [repeat IMAGELEN+data if page needs multiple chunks]
  @PJL SET DOTCOUNT=<black_pixel_count>\r\n
  @PJL SET PAGESTATUS=END\r\n       ← triggers paper ejection

── End of job (once) ──────────────────────────────────────────────────
@PJL EOJ\r\n
ESC%-12345X\r\n

Every line is terminated with \r\n (CRLF). The printer is strict about this; \n alone breaks parsing on some firmware versions.

Building the CUPS filter

The final filter (rastertoricohjbig.c) is about 200 lines of C. The core page-encoding function:

static void write_page(unsigned char *bmp, unsigned w, unsigned h,
                       const char *paper, int first_page,
                       unsigned dpi, int copies)
{
    Buf buf = { malloc(1 << 17), 0, 1 << 17 };
    struct jbg_enc_state enc;
    unsigned char *planes[1] = { bmp };

    if (!first_page) {
        fprintf(stdout,
            "@PJL SET PAGESTATUS=START\r\n"
            "@PJL SET COPIES=%d\r\n"
            "@PJL SET MEDIASOURCE=TRAY1\r\n"
            "@PJL SET MEDIATYPE=PLAINRECYCLE\r\n",
            copies);
    }

    fprintf(stdout,
        "@PJL SET PAPER=%s\r\n"
        "@PJL SET PAPERWIDTH=%u\r\n"
        "@PJL SET PAPERLENGTH=%u\r\n"
        "@PJL SET RESOLUTION=%u\r\n",
        paper, w, h, dpi);

    jbg_enc_init(&enc, w, h, 1, planes, buf_cb, &buf);
    jbg_enc_options(&enc, 0x03, 0x48, 128, 0, 0);
    jbg_enc_out(&enc);
    jbg_enc_free(&enc);

    fprintf(stdout, "@PJL SET IMAGELEN=%zu\r\n", buf.size);
    fwrite(buf.data, 1, buf.size, stdout);

    unsigned long dots = count_dots(bmp, w, h);
    fprintf(stdout,
        "@PJL SET DOTCOUNT=%lu\r\n"
        "@PJL SET PAGESTATUS=END\r\n",
        dots);
    fflush(stdout);
    free(buf.data);
}

The Buf structure is a growable buffer that acts as the jbigkit output callback target. jbigkit calls buf_cb() with encoded chunks, which get appended to the buffer. After encoding, we know the total size, so we can emit IMAGELEN=N followed by the exact bytes. The Linux-generated JBIG streams are small enough that a single IMAGELEN block per page is sufficient. No chunking needed, but the firmware handles both.

The dot count function uses __builtin_popcount to count set bits in the 1-bit packed bitmap:

static unsigned long count_dots(const unsigned char *bmp, unsigned w, unsigned h)
{
    unsigned stride = (w + 7) / 8;
    unsigned long n = 0;
    for (unsigned y = 0; y < h; y++)
        for (unsigned x = 0; x < stride; x++)
            n += __builtin_popcount(bmp[y * stride + x]);
    return n;
}

The PPD file

The PPD (PostScript Printer Description) tells CUPS how to handle this printer. The key directives:

*cupsFilter: "application/vnd.cups-raster 0 rastertoricohjbig"

This registers our filter: for application/vnd.cups-raster input (CUPS’s internal raster format), with priority 0, run rastertoricohjbig.

*ColorDevice: False
*DefaultColorSpace: Gray

Tells CUPS this is a monochrome device. CUPS will convert colour documents to grayscale before they reach our filter.

The paper size definitions use PostScript point dimensions (1/72 inch):

*PageSize A4/A4:     "<</PageSize[595 842]>>setpagedevice"
*PageSize Letter/Letter: "<</PageSize[612 792]>>setpagedevice"

595 × 842 pt = 210 × 297 mm (A4). 612 × 792 pt = 216 × 279 mm (Letter).

The filter uses hdr.PageSize[0] to distinguish paper sizes at runtime:

const char *paper = (hdr.PageSize[0] > 610) ? "LETTER" : "A4";

Letter’s width in points (612) is above the 610 threshold; A4’s (595) is below it.

Getting the margins right

The driver was printing correctly at this point, but there was one minor issue, the pages printed had had no margins on the top and left side. Which is caused by the ImageableArea entries in the PPD and since they were guesses. I had written:

*ImageableArea A4/A4:     "10 10 585 832"
*ImageableArea Letter/Letter: "0 0 603 783"

The A4 values were plausible round numbers. The Letter row was visibly wrong - 0 0 as the lower-left corner means the printer can print all the way to the physical edge of the paper, which no laser printer can do. I’d just copied something and moved on. The right thing to do was find the actual hardware margin from the manufacturer.

Ricoh doesn’t publish a Linux PPD for the SP 200, but they do publish the Windows driver installer: r74156en.exe. Windows driver installers often contain an INF or PPD that documents the imageable area. Time to crack it open.

Step 1: extract the installer

$ mkdir -p /tmp/ricoh_driver
$ 7z x r74156en.exe -o/tmp/ricoh_driver -y

86 files extracted, ~12 MB total. 7z identified the embedded container as a Zip archive with a small trailing “tail”, which is normal for self-extractors. The interesting files landed in two places:

DISK1/          ← actual printer driver payload
INSTDLL/        ← installer UI helpers
NETDLL64/       ← network monitor DLLs
drvinst/        ← driver install tool

Key files in DISK1/:

The .xm_ files looked promising, compressed XML configs are exactly where a Windows driver would store its paper geometry.

Step 2: first attempt: grep the plain-text files

My first instinct was to search the INF and INI files directly:

$ grep -i -E "paper|page|margin|imageable|letter|A4|size|area|dimension" \
    /tmp/ricoh_driver/DISK1/GOEGGDIM.inf

No output. Windows INF files for PostScript drivers usually embed paper data, but this is a DDST/GDI driver-host-based rendering, where the printer is essentially a dumb pixel receiver. The INF handles only install metadata. A wider sweep across everything:

$ grep -r -i -E "imageable|PaperSize|margin|A4|letter|595|842|612|792" \
    /tmp/ricoh_driver/ \
    --include="*.ini" --include="*.txt" --include="*.xml" --include="*.inf"

Two trivial hits: P_ACCPaperSize=3 in a network config INI. Nothing useful. The geometry data wasn’t in any plain-text file.

Step 3: identify the compressed format

Running file on one of the .xm_ files:

$ file /tmp/ricoh_driver/DISK1/goeg_gdimsfpacfg.xm_
goeg_gdimsfpacfg.xm_: MS Compress archive data, SZDD variant,
  l is last character of original name, original size: 225540 bytes

SZDD: Microsoft’s old compress.exe/expand.exe format from the early 90s, still used in some driver packages. It’s a simple LZ77 variant. The original filename was goeg_gdimsfpacfg.xml (the _ replaces the last character, l). Running strings on the compressed file confirmed the contents were XML — the beginning of the decompressed stream leaked through:

<?xml version="1.0" encoding="utf-8"?>
<DeviceCapabilities ...

225,540 bytes of device-capabilities XML, compressed into the .xm_ file.

Step 4: first attempt to decompress: the wrong expand

The obvious move was:

$ expand /tmp/ricoh_driver/DISK1/goeg_gdimsfpacfg.xm_ /tmp/goeg_gdimsfpacfg.xml

This didn’t go as expected. GNU expand converts tabs to spaces. It has nothing to do with Microsoft’s expand.exe decompressor, same name, completely unrelated programs. It just dumped the binary file unchanged.

The correct Linux tools would be cabextract -s or msexpand. Instead of installing new packages, I wrote a decompressor inline (with the help of claude) as the SZDD format is small and fully documented.

Step 5: SZDD decompressor in Python

SZDD is straightforward: a 14-byte header followed by an LZ77 bitstream with a 4096-byte sliding window:

import struct, sys

def szdd_decompress(data):
    magic = b'SZDD\x88\xf0\x27\x33'
    assert data[:8] == magic, "Not SZDD"
    # header: [8] compress_type, [9] last_char, [10:14] orig_size (LE)
    orig_size = struct.unpack_from('<I', data, 10)[0]

    window = bytearray(b' ' * 4096)  # initialized with spaces
    wpos = 4096 - 16                  # write position in window
    out = bytearray()
    i = 14                            # skip header

    while i < len(data):
        ctrl = data[i]; i += 1
        for bit in range(8):
            if i >= len(data):
                break
            if ctrl & (1 << bit):    # literal byte
                b = data[i]; i += 1
                out.append(b)
                window[wpos] = b
                wpos = (wpos + 1) % 4096
            else:                     # back-reference
                lo = data[i]; i += 1
                hi = data[i]; i += 1
                offset = lo | ((hi & 0xf0) << 4)
                length = (hi & 0x0f) + 3
                for _ in range(length):
                    b = window[offset % 4096]
                    out.append(b)
                    window[wpos] = b
                    wpos = (wpos + 1) % 4096
                    offset += 1
    return bytes(out)

with open(sys.argv[1], 'rb') as f:
    data = f.read()
result = szdd_decompress(data)
sys.stdout.buffer.write(result)

Running this on goeg_gdimsfpacfg.xm_ produced 225,540 bytes of clean XML. Exactly the size the SZDD header advertised.

Step 6: search the decompressed XML

The decompressed file is a UPDF (Universal Printer Description Format) device-capabilities XML. The Windows driver’s internal description of everything the printer can do. Grepping for margin-related terms:

$ grep -i -E "imageable|margin|A4|letter|papersize|offset" \
    /tmp/goeg_gdimsfpacfg.xml

The relevant output:

<MediaSizeRecord ID="A4" ClassifyingID="iso_a4_210x297mm"
  HardwareMargins="margins_left-0.182_top-0.182_right-0.182_bottom-0.182in"
  StringID="PAPERSIZE_3009" />
<MediaSizeRecord ID="Letter" ClassifyingID="na_letter_8.5x11in"
  HardwareMargins="margins_left-0.182_top-0.182_right-0.182_bottom-0.182in"
  StringID="PAPERSIZE_3001" />

Every paper size in the entire XML carries the same hardware margin string: 0.182 inches on all four sides. This is the SP 200’s physical unprintable border. It’s a property of the transport mechanism, not a per-paper setting.

There was also a separate element in the XML:

<mti:DefaultPaperOffsets Left="24.0" Top="24.0" Right="24.0" Bottom="24.0" />

I considered whether 24.0 could be the margin in some unit as 24 mm would be far too large (nearly an inch), and 24/100 mm would be far smaller than the explicit 0.182in. The HardwareMargins attribute is explicit, named, and declares its unit (in). The DefaultPaperOffsets are likely rendering-pipeline offsets in the driver’s internal coordinate system. I trusted HardwareMargins.

Step 7: convert to PostScript points

PPD files use PostScript points (1 inch = 72 pt):

0.182 in × 72 pt/in = 13.104 pt ≈ 13.1

The PPD ImageableArea format is llx lly urx ury: lower-left and upper-right corners in points, measured from the bottom-left of the physical paper sheet:

A4 (PaperDimension 595 × 842 pt):

• llx = 13.1 (left margin)
• lly = 13.1 (bottom margin)
• urx = 595 − 13.1 = 581.9
• ury = 842 − 13.1 = 828.9

Letter (PaperDimension 612 × 792 pt):

• llx = 13.1
• lly = 13.1
• urx = 612 − 13.1 = 598.9
• ury = 792 − 13.1 = 778.9

Comparing old vs new:

The fix was two lines in the PPD:

*ImageableArea A4/A4:         "13.1 13.1 581.9 828.9"
*ImageableArea Letter/Letter: "13.1 13.1 598.9 778.9"

Installation and testing

# Compile
gcc -O2 -o rastertoricohjbig rastertoricohjbig.c \
    $(cups-config --libs) -lcupsimage -ljbig

# Install
sudo install -m 755 rastertoricohjbig /usr/lib/cups/filter/rastertoricohjbig
sudo install -m 644 ricoh-sp200.ppd   /usr/share/ppd/cupsfilters/

# Register
sudo lpadmin -p Ricoh_SP_200_DDST \
    -v "$(lpinfo -v | grep -i ricoh | awk '{print $2}' | head -1)" \
    -P /usr/share/ppd/cupsfilters/ricoh-sp200.ppd \
    -E

# Print
echo "Hello from Linux" | lpr -P Ricoh_SP_200_DDST

Multi-page test with lpr -P Ricoh_SP_200_DDST document.pdf now correctly prints all pages in sequence. The printer ejects each page as its PAGESTATUS=END arrives, then pulls the next sheet for the following page.

Summary

The Ricoh SP 200 speaks a completely standard protocol: PJL (Printer Job Language) wrapping JBIG1 (ITU-T T.82) compressed monochrome raster. No proprietary formats, no obfuscation. Everything needed to implement the driver is in public standards documents.

The five bugs discovered along the way, in order:

Bugs 1–4 were found by comparing my driver’s output byte-for-byte against the single-page capture. Bug 5 required a second capture specifically of a multi-page job, the single-page capture gave no hint of the page lifecycle protocol that the firmware required.

The margins were a separate research step entirely: not a bug that produced a wrong output, but a gap that would have made the driver subtly incorrect at the edges. Getting them right required cracking open the Windows installer, navigating a compressed XML format, and learning that GNU expand and Microsoft expand.exe share a name and nothing else.

The complete source is on GitHub . If you have a Ricoh SP 200 and have been running a Windows VM just to print, you no longer have to.
